Breaking Down X's Open Source Algorithm

X just did something rare in the tech industry. They published the complete source code for their For You feed algorithm. Not a simplified version. Not a whitepaper. The actual production code that decides what 500 million daily active users see.

For engineers, this is a goldmine. We can finally see how a platform at this scale builds a recommendation system. The choices they made. The trade-offs they accepted. The patterns they invented.

I spent the last few days going through the xai-org/x-algorithm repository. Here’s everything I learned.

The Problem X Had to Solve

Every time you open X and see the For You tab, the platform faces an impossible problem:

• 500 million posts are created daily
• Millions of users are requesting their feed simultaneously
• Each feed must be personalized in real-time
• The response time must be under 200 milliseconds

Traditional approaches break at this scale. You cannot run a neural network on 500 million posts for every user. You cannot even run it on 10 million. The computational cost would be astronomical.

So X built a funnel. A multi-stage pipeline that progressively narrows down candidates until only the most relevant survive.

System Architecture: The 10,000 Foot View

The algorithm follows a simple funnel. Start with millions of posts, narrow down to thousands, score them, and return the best ones:

flowchart LR
    subgraph Stage1[" "]
        direction TB
        A1[500M Posts]
        A2[Thunder]
        A3[Phoenix Retrieval]
    end

    subgraph Stage2[" "]
        B[1,500 Candidates]
    end

    subgraph Stage3[" "]
        C[Grok Transformer]
    end

    subgraph Stage4[" "]
        D[Filters]
    end

    subgraph Stage5[" "]
        E[Your Feed]
    end

    A1 --> A2
    A1 --> A3
    A2 --> B
    A3 --> B
    B --> C
    C --> D
    D --> E

    style Stage1 fill:#f8f9fa,stroke:#dee2e6
    style Stage2 fill:#e3f2fd,stroke:#1976d2
    style Stage3 fill:#fff8e1,stroke:#f9a825
    style Stage4 fill:#e8f5e9,stroke:#388e3c
    style Stage5 fill:#e0f2f1,stroke:#00897b

The four main components:

Let me break down each component.

Home Mixer: The Orchestration Layer

View source on GitHub

Home Mixer is the brain that coordinates everything. When a request comes in, it runs through a well-defined pipeline:

flowchart LR
    subgraph S1[" "]
        A[Hydrate<br/>User Context]
    end
    subgraph S2[" "]
        B[Fetch<br/>Candidates]
    end
    subgraph S3[" "]
        C[Enrich<br/>Metadata]
    end
    subgraph S4[" "]
        D[Filter<br/>Invalid]
    end
    subgraph S5[" "]
        E[Score<br/>ML Model]
    end
    subgraph S6[" "]
        F[Select<br/>Top K]
    end
    subgraph S7[" "]
        G[Final<br/>Filters]
    end

    A --> B --> C --> D --> E --> F --> G

    style S1 fill:#e3f2fd,stroke:#1976d2
    style S2 fill:#e3f2fd,stroke:#1976d2
    style S3 fill:#e3f2fd,stroke:#1976d2
    style S4 fill:#fff8e1,stroke:#f9a825
    style S5 fill:#fff8e1,stroke:#f9a825
    style S6 fill:#e8f5e9,stroke:#388e3c
    style S7 fill:#e8f5e9,stroke:#388e3c

The clever part is the separation between what gets fetched and what gets scored. You can change the scoring model without touching the data layer. You can add new data sources without rewriting the scorer.

This is the Candidate Pipeline pattern (source). X built it as a reusable framework with clear interfaces:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
// Simplified version of the pipeline traits
trait Source {
    fn fetch_candidates(query: &Query) -> Vec<Candidate>;
}

trait Hydrator {
    fn enrich(candidate: &mut Candidate);
}

trait Filter {
    fn should_include(candidate: &Candidate) -> bool;
}

trait Scorer {
    fn score(candidates: &[Candidate]) -> Vec<ScoredCandidate>;
}

trait Selector {
    fn select(scored: Vec<ScoredCandidate>, limit: usize) -> Vec<Candidate>;
}

Each trait has a single responsibility. The framework handles parallel execution, error handling, and monitoring. This is textbook SOLID principles applied at scale.

Thunder: The In-Network Post Store

View source on GitHub

Thunder is an in-memory post store. It tracks recent posts from all users and serves them at sub-millisecond latency.

flowchart LR
    subgraph Input[" "]
        K[Kafka Events]
    end

    subgraph Thunder["Thunder In-Memory Store"]
        direction TB
        P1[(Posts)]
        P2[(Replies)]
        P3[(Videos)]
    end

    subgraph Output[" "]
        Q[Feed Query]
        R[Candidates]
    end

    K --> Thunder
    Q --> Thunder
    Thunder --> R

    style Input fill:#f8f9fa,stroke:#dee2e6
    style Thunder fill:#e3f2fd,stroke:#1976d2
    style Output fill:#e8f5e9,stroke:#388e3c

When you ask for your feed, Thunder looks at who you follow and returns their recent posts. No database queries. No network hops. Everything lives in memory, partitioned by user.

Key design choice: Thunder maintains separate stores for different post types. Original posts, replies, reposts, and videos each have their own storage. This allows different retention policies and query patterns for each type.

The retention period is configurable. Posts older than the threshold get automatically trimmed. This keeps memory usage bounded while ensuring fresh content is always available.

Phoenix: The ML Powerhouse

View source on GitHub

Phoenix is where the machine learning happens. It has two main jobs:

1. Retrieval (Two-Tower Model)

Finding relevant out-of-network posts is a needle-in-a-haystack problem. Phoenix solves it with a Two-Tower architecture:

flowchart LR
    subgraph Left["User Tower"]
        U1[Your Likes]
        U2[Your Follows]
        U3[Your History]
        UE[Encoder]
        UV[User Vector]
    end

    subgraph Right["Candidate Tower"]
        C1[Post Text]
        C2[Post Media]
        C3[Author Info]
        CE[Encoder]
        CV[Post Vector]
    end

    subgraph Match[" "]
        S["Similarity<br/>Search"]
        R[Top-K Posts]
    end

    U1 --> UE
    U2 --> UE
    U3 --> UE
    UE --> UV

    C1 --> CE
    C2 --> CE
    C3 --> CE
    CE --> CV

    UV --> S
    CV --> S
    S --> R

    style Left fill:#e3f2fd,stroke:#1976d2
    style Right fill:#fff8e1,stroke:#f9a825
    style Match fill:#e8f5e9,stroke:#388e3c

The User Tower encodes your features and engagement history into a 512-dimensional vector. The Candidate Tower does the same for all posts. Finding relevant posts becomes a similarity search: which post embeddings are closest to your user embedding?

This is the same pattern used in vector databases and RAG systems. The difference is scale. X runs this across billions of posts in real-time.

2. Ranking (Grok Transformer with Candidate Isolation)

Once candidates are retrieved, they need to be ranked. Phoenix uses a transformer model based on xAI’s Grok architecture, but with a twist: candidate isolation.

flowchart LR
    subgraph Inputs[" "]
        direction TB
        UC[User Context]
        P1[Post 1]
        P2[Post 2]
        P3[Post N]
    end

    subgraph Model["Grok Transformer"]
        direction TB
        M[Attention with<br/>Candidate Isolation]
    end

    subgraph Scores["Predictions"]
        direction TB
        S1["Like: 0.8"]
        S2["Reply: 0.3"]
        S3["Repost: 0.5"]
        S4["Block: 0.01"]
    end

    UC --> M
    P1 --> M
    P2 --> M
    P3 --> M
    M --> S1
    M --> S2
    M --> S3
    M --> S4

    style Inputs fill:#f8f9fa,stroke:#dee2e6
    style Model fill:#fff8e1,stroke:#f9a825
    style Scores fill:#e8f5e9,stroke:#388e3c

Why candidate isolation matters: In a normal transformer, every token can attend to every other token. If you batch 100 posts together, each post’s score would depend on which other posts are in the batch. Run the same post in a different batch, get a different score.

That’s a problem for caching and consistency. X solves it by masking the attention. Candidates can see the user context but not each other. The score for Post A is always the same, regardless of what other posts are being scored.

This is a brilliant trade-off. You lose some potential signal (maybe posts should be compared to each other) but you gain:

• Consistent scores that can be cached
• Parallel batch processing without ordering effects
• Simpler debugging since scores are deterministic

The Scoring Formula

The transformer predicts probabilities for multiple engagement types. The final score is a weighted sum:

flowchart LR
    subgraph Positive["Positive Signals"]
        direction TB
        L["Like × 0.5"]
        RP["Reply × 0.3"]
        RT["Repost × 1.0"]
        F["Follow × 4.0"]
    end

    subgraph Negative["Negative Signals"]
        direction TB
        B["Block × -3.0"]
        M["Mute × -2.0"]
        R["Report × -5.0"]
    end

    subgraph Result[" "]
        S["Final Score"]
    end

    Positive --> S
    Negative --> S

    style Positive fill:#e8f5e9,stroke:#388e3c
    style Negative fill:#ffebee,stroke:#c62828
    style Result fill:#e3f2fd,stroke:#1976d2

Here’s what we know about the weights from the source code:

Notice how negative signals carry massive weights. A single block is worth -3.0, while a like is only +0.5. The algorithm heavily penalizes content you’d find annoying.

This is the key insight: X optimizes for long-term user retention, not short-term engagement. Showing you rage-bait that gets clicks but makes you block the author is a net negative.

Filtering: The Safety Net

Before and after scoring, posts go through extensive filtering:

Pre-Scoring Filters

Post-Selection Filters

The pre-scoring filters run on all candidates. The post-selection filters run only on the final selected posts. This ordering minimizes compute. Why score a post that’ll be filtered anyway?

The Tech Stack

Looking at the repository structure reveals interesting language choices:

Rust (62.9%): Used for high-performance components

• Thunder (in-memory post store)
• Candidate Pipeline framework
• Real-time serving infrastructure

Python (37.1%): Used for ML components

• Phoenix model training
• Embedding generation
• Offline analysis

This is a common pattern in ML systems. Python for flexibility during model development, Rust for performance in production serving. The Rust compilation ensures memory safety and predictable latency.

Design Patterns Worth Stealing

1. The Candidate Pipeline Pattern

View source on GitHub

Instead of a monolithic recommendation function, X breaks everything into composable stages:

1
2
3
4
5
6
7
pipeline
    .with_sources(vec![thunder_source, phoenix_retrieval])
    .with_hydrators(vec![core_data, author_info, video_duration])
    .with_filters(vec![age_filter, blocked_filter, seen_filter])
    .with_scorers(vec![phoenix_scorer, weighted_scorer, diversity_scorer])
    .with_selector(top_k_selector)
    .execute(query)

You can swap any component without touching others. Add a new data source? Write a new Source implementation. Change ranking logic? Swap the Scorer. This is the Strategy Pattern at a system level.

2. Hash-Based Embeddings

Vocabulary size in recommendation systems can be enormous. Millions of users, millions of posts, millions of keywords. Traditional embedding tables would use too much memory.

X uses hash embeddings. Instead of a unique embedding per entity, they hash entity IDs into a fixed number of buckets. Multiple entities might share an embedding, but with enough buckets and multiple hash functions, collisions average out.

1
2
3
4
5
6
7
# Simplified concept
def get_embedding(entity_id, num_buckets=1_000_000, num_hashes=4):
    embeddings = []
    for i in range(num_hashes):
        bucket = hash(f"{entity_id}_{i}") % num_buckets
        embeddings.append(embedding_table[bucket])
    return average(embeddings)

This trades some precision for massive memory savings. At X’s scale, that trade-off makes sense.

3. Multi-Task Prediction

Instead of training separate models for each engagement type, Phoenix predicts all actions simultaneously. The shared representation learns general patterns while task-specific heads learn action-specific nuances.

flowchart LR
    subgraph In[" "]
        I[Post + User]
    end

    subgraph Core[" "]
        T[Shared Layers]
    end

    subgraph Heads["Task Heads"]
        H1[Like]
        H2[Reply]
        H3[Repost]
        H4[Block]
    end

    subgraph Out["Probabilities"]
        P1["0.72"]
        P2["0.31"]
        P3["0.45"]
        P4["0.02"]
    end

    I --> T
    T --> H1 --> P1
    T --> H2 --> P2
    T --> H3 --> P3
    T --> H4 --> P4

    style In fill:#f8f9fa,stroke:#dee2e6
    style Core fill:#e3f2fd,stroke:#1976d2
    style Heads fill:#fff8e1,stroke:#f9a825
    style Out fill:#e8f5e9,stroke:#388e3c

Multi-task learning often outperforms single-task models because tasks share underlying patterns. Someone who likes a post might also repost it. The model can learn this correlation.

What They Explicitly Avoided

The README is surprisingly candid about what they removed:

We have eliminated every single hand-engineered feature and most heuristics from the system.

This means:

• No explicit features for post length, media type, or posting time
• No hard-coded boost for verified accounts
• No manual trending topic signals
• No recency bias beyond what the model learns

Everything goes through the transformer. If a pattern matters (like people engaging more with video posts), the model learns it from data.

This is a bold architectural choice. Hand-crafted features give you control. You can boost breaking news manually. You can explicitly downrank certain content types. X chose to give up that control in favor of letting the model optimize directly for engagement signals.

Lessons for Your Own Recommendation System

1. Build a Pipeline, Not a Model

The algorithm is not one giant model. It’s a system of specialized components. This separation means:

• Teams can work independently
• Components can be tested in isolation
• Changes have limited blast radius
• You can A/B test at any stage

If you’re building recommendations, start with the pipeline architecture. The ML model is just one component.

2. Negative Signals Are More Important Than Positive

Look at those weights again. Blocking is worth 6x more (negatively) than liking (positively). This reflects a fundamental truth: people tolerate mediocre recommendations but leave platforms that consistently annoy them.

When designing your scoring, make sure negative signals have teeth. A report should dramatically impact future recommendations.

3. Candidate Isolation Enables Caching

By ensuring each post’s score is independent, X can cache scores aggressively. If you’ve already scored a post for a user, use the cached score. Only compute new scores for new posts.

This simple invariant (same input always gives same output) enables massive performance optimizations.

4. Latency Trumps Accuracy

X serves hundreds of millions of requests per day. A 50ms latency increase would be catastrophic. Throughout the codebase, you see choices that prioritize speed:

• In-memory post stores
• Rust for serving
• Batch processing with isolation
• Aggressive filtering before expensive scoring

Your recommendation system’s best model is useless if it’s too slow to serve.

5. Invest in the Framework

X built Product Mixer and the Candidate Pipeline framework as reusable infrastructure. Yes, it was extra upfront work. But now every team building feeds (For You, Search, Explore) uses the same patterns.

If you’re doing recommendations across multiple surfaces, build your pipeline framework once. The consistency and code reuse pays off quickly.

What’s Missing from the Open Source Release

A few notable gaps:

Training Infrastructure: We see the model architecture but not how they train at scale. The data pipelines, distributed training setup, and hyperparameter tuning remain private.

Real-time Features: The code shows static scoring but not how they incorporate live signals (current trending topics, breaking news, viral posts).

A/B Testing Framework: How do they test changes? What’s their experiment infrastructure? Not included.

Operational Runbooks: How do they handle outages? What are the alert thresholds? The operational side is absent.

Still, what they did release is remarkably complete. You could reconstruct a working recommendation system from this code.

The Bigger Picture

This release represents a shift in how we think about algorithm transparency. For years, social media algorithms were black boxes. Users complained about seeing (or not seeing) content without understanding why.

X’s response is radical transparency. Here’s the code. Here’s how it works. If you don’t like it, at least now you know what to change.

Whether this level of openness becomes an industry norm remains to be seen. But for engineers, it’s a gift. We get to learn from one of the most scaled recommendation systems on the planet.

The next time you scroll through For You, you’ll know exactly what’s happening behind the scenes. Candidate sourcing. Grok transformer. Weighted scoring. Filtering.

500 million posts. 1,500 candidates. Your personalized feed.

And now you know how it works.

For more system design deep dives, check out our posts on How Kafka Works, How Slack Built a System That Handles 10+ Billion Messages, and Vector Databases and RAG. Want to understand the patterns behind recommendation systems? Explore our Design Patterns guide.
