Kubernetes Architecture: The Operating System for the Cloud

Six months ago, you had one web app on one server. Today, you have 50 microservices that need to scale independently, find each other, and handle failures gracefully. Your deployment process went from “upload via FTP” to “run this 200 line script and pray.”

This is exactly why Kubernetes exists.

Kubernetes is essentially an operating system for distributed applications. Just like Linux manages processes and memory on one machine, Kubernetes manages containers and resources across a cluster of machines.

Let’s break down how it actually works and what you need to know as a developer.

The Problem: Why We Need an Orchestrator

How Google Ran Its Infrastructure

By the early 2000s, Google was running billions of containers across thousands of servers. They needed to manage services like Search, Gmail, Maps, and YouTube at massive scale. Manual deployment and management was impossible.

Google built internal systems to solve this:

Borg (2003): Their first container orchestration system
Omega (2013): An improved version with better scheduling

These systems handled:

Automated deployment: Deploy thousands of containers without manual intervention
Resource efficiency: Pack services tightly to maximize hardware utilization
Self healing: Automatically restart failed containers
Zero downtime updates: Deploy new versions without taking services offline
Global scale: Coordinate containers across multiple datacenters

In 2014, Google open sourced Kubernetes - a reimagining of Borg for the wider world. They realized every company moving to microservices would face the same problems they solved internally.

The timing was perfect. Docker had made containers popular, but nobody had a good way to run them at scale.

Kubernetes: The Big Picture

Kubernetes solves the orchestration problem by providing a declarative API for managing containerized applications. Instead of telling Kubernetes how to do something, you tell it what you want, and it figures out the how.

Here’s the key insight: Kubernetes treats your entire cluster as a single computer. You don’t deploy to specific servers - you deploy to “the cluster” and Kubernetes decides where things should run.

graph TB
    subgraph "Traditional Deployment"
        Dev1[Developer] --> Server1[Web Server 1]
        Dev1 --> Server2[Web Server 2]
        Dev1 --> Server3[Database Server]
        Dev1 --> Server4[Cache Server]
    end

    subgraph "Kubernetes Deployment"
        Dev2[Developer] --> K8s[Kubernetes Cluster]
        K8s --> Pod1[Web Pods]
        K8s --> Pod2[Database Pods]
        K8s --> Pod3[Cache Pods]
        K8s --> Pod4[Background Job Pods]
    end

This abstraction is powerful because it lets developers focus on their applications instead of infrastructure management.

The Architecture: Control Plane vs Worker Nodes

Kubernetes uses a control plane and worker nodes architecture. Think of it like a construction site:

Control Plane: The project managers and architects who make decisions
Worker Nodes: The construction workers who do the actual building

graph TB
    subgraph "Control Plane"
        API[kube-apiserver<br/>📡 API Gateway]
        ETCD[etcd<br/>🗄️ Cluster Database]
        SCHED[kube-scheduler<br/>📋 Pod Placement]
        CM[kube-controller-manager<br/>🎛️ State Management]
    end

    subgraph "Worker Node 1"
        KUBELET1[kubelet<br/>🤖 Node Agent]
        PROXY1[kube-proxy<br/>🌐 Network Proxy]
        RUNTIME1[Container Runtime<br/>📦 Docker/containerd]
        POD1[Pods<br/>🏠 Application Containers]
    end

    subgraph "Worker Node 2"
        KUBELET2[kubelet<br/>🤖 Node Agent]
        PROXY2[kube-proxy<br/>🌐 Network Proxy]
        RUNTIME2[Container Runtime<br/>📦 Docker/containerd]
        POD2[Pods<br/>🏠 Application Containers]
    end

    API --> KUBELET1
    API --> KUBELET2
    API --> ETCD
    API --> SCHED
    API --> CM

    KUBELET1 --> RUNTIME1
    KUBELET2 --> RUNTIME2
    RUNTIME1 --> POD1
    RUNTIME2 --> POD2

Let’s dive into each component and understand what they actually do.

Control Plane Components: The Brain of Kubernetes

kube-apiserver: The Front Door

The API server is the only component that talks to etcd and the only way anything else communicates with the cluster. Every kubectl command, every internal component, every external tool - everything goes through the API server.

Think of it as the receptionist at a busy office. Every request comes to them first, they validate who you are, check if you’re allowed to do what you’re asking, and then either fulfill the request or pass it to the right person.

Real world example: When you run kubectl apply -f deployment.yaml, here’s what happens:

kubectl sends the YAML to the API server
API server validates the YAML syntax
API server checks if you have permission to create deployments
API server stores the deployment spec in etcd
API server notifies other components that a new deployment exists

etcd: The Single Source of Truth

etcd is a distributed key-value store that holds the entire state of your Kubernetes cluster. Every pod, service, secret, and configuration lives here. It’s like the master database for your entire infrastructure.

Why etcd and not a regular database?

Consistency: etcd uses the Raft consensus algorithm to ensure all nodes agree on the data
Watch API: Components can subscribe to changes in real-time
Atomic operations: Critical for maintaining cluster state integrity

What’s stored in etcd:

/registry/pods/default/my-app-pod-123
/registry/services/default/my-app-service
/registry/deployments/default/my-app-deployment
/registry/secrets/default/database-credentials

kube-scheduler: The Matchmaker

The scheduler’s job is to decide which node should run each pod. It’s like a really smart HR person matching job requirements with candidate qualifications.

The scheduling process:

Filtering: Remove nodes that can’t run the pod (not enough CPU, wrong OS, etc.)
Scoring: Rank remaining nodes based on various factors
Selection: Pick the highest-scoring node

Scheduling factors:

Resource requirements (CPU, memory, storage)
Node affinity rules (“run on nodes with SSD storage”)
Pod affinity rules (“run near the database pods”)
Anti-affinity rules (“don’t run two instances on the same node”)
Taints and tolerations (node restrictions)

kube-controller-manager: The Autopilot

This is actually multiple controllers running in a single process. Each controller watches for changes and tries to make the actual state match the desired state.

Key controllers:

Deployment Controller: Manages ReplicaSets for deployments
ReplicaSet Controller: Ensures the right number of pod replicas
Node Controller: Monitors node health and marks unhealthy nodes
Service Account Controller: Creates default service accounts for namespaces

Example: If you have a deployment with 3 replicas but only 2 pods are running, the ReplicaSet controller will create a new pod to match the desired state.

Worker Node Components: Where the Work Happens

kubelet: The Node Manager

The kubelet is the primary node agent that runs on every worker node. It’s responsible for:

Pod Lifecycle Management: Starting, stopping, and monitoring containers
Health Checks: Running liveness and readiness probes
Resource Monitoring: Reporting node and pod resource usage
Volume Management: Mounting and unmounting storage volumes

How kubelet works:

Watches the API server for pods assigned to its node
Pulls container images from registries
Starts containers using the container runtime
Monitors container health and restarts failed containers
Reports status back to the API server

kube-proxy: The Network Plumber

kube-proxy handles network routing for services. When you create a Kubernetes service, kube-proxy sets up the networking rules to make it accessible.

What kube-proxy does:

Creates iptables rules (or uses IPVS) for service routing
Load balances traffic across pod replicas
Handles service discovery within the cluster

Example: You have a service called “database” with 3 pod replicas. kube-proxy ensures that when any pod tries to connect to “database”, the traffic gets routed to one of the healthy replicas.

Container Runtime: The Engine

This is what actually runs your containers. Kubernetes supports multiple runtimes:

containerd: The most common choice, used by major cloud providers
CRI-O: Red Hat’s container runtime
Docker: Still supported but being phased out

The runtime handles:

Pulling container images
Creating and starting containers
Managing container lifecycle
Providing container logs and metrics

How It All Works Together: A Pod’s Journey

Let’s trace what happens when you deploy a simple web application to understand how all these components work together.

Step 1: You Submit a Deployment

apiVersion: apps/v1
kind: Deployment
metadata:
  name: web-app
spec:
  replicas: 3
  selector:
    matchLabels:
      app: web-app
  template:
    metadata:
      labels:
        app: web-app
    spec:
      containers:
      - name: web
        image: nginx:1.21
        ports:
        - containerPort: 80

Step 2: Control Plane Processes the Request

sequenceDiagram
    participant User
    participant API as kube-apiserver
    participant ETCD as etcd
    participant Deploy as Deployment Controller
    participant RS as ReplicaSet Controller
    participant Sched as kube-scheduler

    User->>API: kubectl apply -f deployment.yaml
    API->>ETCD: Store deployment spec
    API->>User: Deployment created

    Deploy->>API: Watch for deployments
    API->>Deploy: New deployment detected
    Deploy->>API: Create ReplicaSet
    API->>ETCD: Store ReplicaSet spec

    RS->>API: Watch for ReplicaSets
    API->>RS: New ReplicaSet detected
    RS->>API: Create 3 pods
    API->>ETCD: Store pod specs

    Sched->>API: Watch for unscheduled pods
    API->>Sched: 3 pods need scheduling
    Sched->>API: Assign pods to nodes
    API->>ETCD: Update pod specs with node assignments

Step 3: Worker Nodes Execute the Plan

sequenceDiagram
    participant API as kube-apiserver
    participant Kubelet as kubelet
    participant Runtime as Container Runtime
    participant Registry as Image Registry

    Kubelet->>API: Watch for pods on my node
    API->>Kubelet: Pod assigned to your node
    Kubelet->>Runtime: Start pod containers
    Runtime->>Registry: Pull nginx:1.21 image
    Registry->>Runtime: Image downloaded
    Runtime->>Runtime: Create and start container
    Runtime->>Kubelet: Container running
    Kubelet->>API: Pod status: Running

Real World Lessons: What Developers Need to Know

1. Kubernetes is Eventually Consistent

Unlike traditional systems where changes happen immediately, Kubernetes is eventually consistent. When you apply a change, it might take a few seconds (or longer) for the system to reach the desired state.

Practical implication: Don’t expect immediate results. Use kubectl wait to monitor deployments.

2. Everything is Declarative

You don’t tell Kubernetes “start 3 containers.” You tell it “I want 3 replicas running.” If containers crash, Kubernetes automatically restarts them to maintain your desired state.

Practical implication: Focus on describing what you want, not how to achieve it.

3. Labels are Everything

Kubernetes uses labels and selectors to connect resources. Services find pods using labels. Deployments manage ReplicaSets using labels. Network policies apply to pods using labels.

Best practice: Use consistent, meaningful labels across all your resources.

4. Resource Limits Matter

Without resource limits, a single pod can consume all node resources and crash other applications. Always set CPU and memory limits.

Example:

resources:
  requests:
    cpu: 100m      # 100 millicores = 0.1 CPU core (10%)
    memory: 128Mi  # 128 Mebibytes ≈ 134 MB
  limits:
    cpu: 500m      # 500 millicores = 0.5 CPU core (50%)
    memory: 512Mi  # 512 Mebibytes ≈ 537 MB

Not sure what these units mean? Check out our Kubernetes Resource Units Explained guide for a detailed breakdown of CPU and memory notation.

5. Health Checks are Critical

Kubernetes needs to know if your application is healthy. Configure probes to help Kubernetes make smart decisions about traffic routing and pod restarts.

livenessProbe:    # "Is my container alive?" - Restarts if fails
  httpGet:
    path: /health
    port: 8080
  initialDelaySeconds: 30
  periodSeconds: 10
readinessProbe:   # "Ready for traffic?" - Removes from service if fails
  httpGet:
    path: /ready
    port: 8080
  initialDelaySeconds: 5
  periodSeconds: 5
startupProbe:     # "Finished starting?" - For slow-starting apps
  httpGet:
    path: /startup
    port: 8080
  failureThreshold: 30  # Allow 5 minutes to start

Probe types:

Liveness: Restarts container when it fails (deadlock detection)
Readiness: Controls traffic flow (startup/dependency checks)
Startup: Extended grace period for slow-starting applications

Common Pitfalls and How to Avoid Them

1. Treating Pods Like VMs

Wrong approach: SSH into pods to debug issues, store data locally, manually configure pods.

Right approach: Treat pods as cattle, not pets. Use logs for debugging, external storage for data, and configuration through ConfigMaps and Secrets.

2. Misunderstanding Networking

Kubernetes networking can be complex. Pods can communicate with each other by default, but services provide stable endpoints and load balancing.

Key concepts:

Pod-to-Pod: Direct communication using pod IPs
Service-to-Pod: Stable endpoint with load balancing
External-to-Service: Ingress controllers or LoadBalancer services

3. Ignoring Security

Running containers as root, using default service accounts, and storing secrets in plain text are common security mistakes.

Security checklist:

Run containers as non-root users
Use specific service accounts with minimal permissions
Store sensitive data in Secrets, not ConfigMaps
Enable network policies to restrict pod communication
Regularly scan container images for vulnerabilities

The Bigger Picture: Why Kubernetes Won

Kubernetes succeeded because it solved real problems that every organization faces when scaling applications:

Standardization: One API for all cloud providers
Extensibility: Custom resources and operators for complex applications
Community: Massive ecosystem of tools and integrations
Declarative Management: Infrastructure as code for applications
Self-Healing: Automatic recovery from failures

Conclusion

Kubernetes might seem complex at first, but its architecture is actually quite elegant. By separating concerns between the control plane (decision making) and worker nodes (execution), it creates a scalable, resilient platform for running distributed applications.

Want to dive deeper? Check out the official Kubernetes documentation and try running a local cluster with kind or minikube.
